A corrosion resistant 6Mo alloy similar to AL6XN and SMO254

•

  Higher corrosion resistant substitute for 316L
• Corrosion resistance comparable to Super Duplex 2507
• Similar chemistry to AL6XN and SMO 254
• Chemistry and specifications of Alloy 926
• Availability and lead times
• Alloy 926 fastener styles

Alloy 926 (1.4529) screws are the perfect substitute for 316L when higher corrosion resistance is required without additional strength. Alloy 926 fasteners are considered a 6-Moly alloy (6 Mo or 6% Molybdenum) like sister alloys AL6XN and SMO 254. Within the class of stainless steels, these 6 Mo alloys are considered to be very corrosion resistant. Bolts made from Alloy 926 are a super-austenitic molybdenum stainless steel offering corrosion resistance comparable to Super Duplex 2507 but with slightly lower strength and cost. Almost identical in chemistry to 6 Moly alloys AL6XN and SMO 254, Alloy 926 is often chosen for paper plants, desalination and weak acid environements.

In addition, Alloy 926 fasteners are also similar in composition to 904L, but with increased nitrogen and molybdenum providing Alloy 926 bolts improved general corrosion resistance as well as resistance to pitting and crevice corrosion. Because of Alloy 926 resistance to chloride stress corrosion cracking, it makes 926 fasteners ideal for use in desalination, and pulp and paper plants. This alloy is also good option for diluted sulfuric and phosphorus acid applications.

Mechnical Properties
o  Tensile Strength: 94 ksi
o  Yield Strength: 43 ksi
o  Elongation: 35%
o  Rockwell B Hardness: 86
o  Density: 0.29 lb/in^3
o  Temperature Limits: 750oF / 400oC

Alloy 926 Fastener Availability

Availability
Special Fasteners China. & Fasteners offers Alloy 926 fasteners including many types of screws, nuts, washers and threaded products. Typicially, we have minimum order quantity of 20 pieces for most fasteners. Lead time for production for Alloy 926 fasteners is about 3-4 weeks, depending on the complexity and quantity.

• Diameter sizes:  Standard #00 – 4” in diameter / Metric M1.2 – M48
• Threads: UNC, UNF, UNJ, UNR, Rolled,and Cut
• Custom to print available.
• ASTM, ASME, and Domestic available

Expediting Options
We understand that many applications require a fast lead time. If you need expedited shipping, please let us know when submitting a quote so that we can do our best to accommodate your specific needs.

Alloy 926 Fastener Styles

Alloy 926 (1.4529) Chemistry & Specifications

Alloy 926 (1.4529) Chemistry

Alloy 926 Screws

12 Point Screws	Alloy 926 12 point screws are typically used for applications when higher torque than socket head cap screws is required. We offer 12 points in 1/4" diameter or larger. The only drawback is Alloy 926 12 point screws are less economical and require a high minimum quantity due to the complexity of production.	o  IFI-115 o  MIL SPEC o  DIN 34822 o  DIN 34821
Button Head Cap Screws	When a wide clamping area and low profile fastener is needed, Alloy 926 button head cap screws are an ideal choice. Button head screws are also used for fastening a material that is too thin to counter bore.	o ASME B18.3 o ASME 18.3.4M o DIN 7380 / ISO 7380
Flat Head Screws	Alloy 926 flat head screws have a standard 82° countersink angle, typically with a slotted or socket driver. Flat heads are also available with angles ranging from 60° -120° upon request. Phillips, torx and tamperproof drivers are also available depending on size, quantity and material.	o  ASME B18.3 o  ASME B18.3.6 o  DIN 963 / ISO 2009 o  DIN 965 / ISO 7046 o  DIN 7991 / ISO 10642
Hex Head Cap Screws	Perhaps the most common fastener are Alloy 926 hex head cap screws. These feature an added washer face providing tighter dimensional tolerances over a hex bolt which lacks this element. Alloy 926 hex head cap screws provide high clamping force and easy access.	o ASME B18.6.3 o DIN 931 / ISO 4014 o DIN 933 / ISO 4017 o DIN 961 / ISO 8676
Pan Head Screws	Alloy 926 pan head screws have a rounded head and are best for small diameter and low torque application. They typically feature a slotted driver.	o ASME B18.6.3 o DIN 7985 o DIN 921 o DIN 85 / ISO 1580 o DIN 84 / ISO 1207   (cheese head) o DIN 966 / ISO 7047   (raised counter sunk)
Security Screws	When unwanted removal or tampering is critcal, Alloy 926 security screws provide protection because they cannot be unfastened using an common driver. Tamper-proof screws are produced in a wide variety of head styles, as well as custom per print.
Set Screws	Alloy 926 set screws are a headless fastener that have a slotted or socket driver and a unique point end. Set screws are available with cup, cone, flat, dog and half-dog points.	o ASME B18.3 o DIN 913 / ISO 4026 o DIN 914 / ISO 4027 o DIN 915 / ISO 4028 o DIN 916 / ISO 4029
Socket Head Cap Screws	For safe, secure fastening in low clearance applications, Alloy 926 socket head cap screws are often the fastener of choice.	o ASME B18.3 o DIN 912 / ISO 4762 o DIN 7984
Vented Screws	Alloy 926 vented screws provide a way to out-gas application contaminents through a vertical hole drilled from the screw head through the threaded shaft. Vented screws are ideal for vacuums / high vacuums. Nimonic vented screws are available a variety of head styles.

Alloy 926 Bolts

Hex Head Bolts	Alloy 926 hex head bolts are similar to hex head cap screws but without the washer face . They are a good choice when high clamping force needed for easily accessible applications.	o ASME B18.2.1 o DIN 931 / ISO 4014 o DIN 933 / ISO 4017
Shoulder Bolts	Alloy 926 shoulder bolts feature a head, smooth shoulder section (for rotating parts) and botttom threaded segment. Shoulder bolts typically have a socket driver.	o ASME o DIN 7379 / ISO 7379 o ISO 7370

Alloy 926 Nuts

Hex Nuts	Alloy 926 nuts are available in several styles including: finished hex nuts, jam nuts and heavy hex nuts.	o ASME B18.16.3 o ASME B18.2.2 o DIN 439 / ISO 4035 o DIN 934 / ISO 4032 o DIN 986
Lock Nuts	Alloy 926 lock nuts are offered as all-metal and polymer/nylon insert styles. All-metal lock nuts such as stover and flexloc are ideal for high temperatures and even load distribution. Alloy 926 nylon (polymer) insert lock nuts are more economic but can only be used when temperatures are under 350°F.	o ASME B18.16.3M o DIN 980 / ISO 7042 /     ISO 19513 o DIN 6923 / ISO 4161 o DIN 985 / ISO 10511 /   ISO 7040

Alloy Studs & Threaded Rod

Studs	Alloy 926 are threaded rods less than one foot in length. They can be fully or partially threaded (such as double ended studs) and are available in any custom length.	o ASME B18.31.2 o DIN 976
Threaded Rod	Alloy 926 threaded rods are available in any custom length greater than 1 foot. The minimum order quantity for threaded rod is 6 feet of total length (for example 2, 3-foot pieces) and our maximum shipment length is 6 feet.	o ASME B1.1 o DIN 975

Alloy 926 Washers

Flat Washers	Alloy washers are availble in several specifications including SAE, USS, DIN, oversized, and custom per print.	o ASME 18.21.1 o SAE / USS o DIN 125 / ISO 7089 /   ISO 7090 o DIN 126 / ISO 7091
Lock Washers	Alloy 926 lock washers are available as a split lock washer style.	o ASME B18.21.1 o DIN 127 / ISO 7090 o DIN 6796 /  ISO 10690
